HOFTRONIC™ - Flicker-free LED Driver - for Hoftronic 21W LED Panel (180lm/W) - Non dimmable
- Article number: 5448065
INTOLED delivery time
Delivery time
We do everything to deliver the ordered items to you on time. In some cases, circumstances may cause a delivery to be delayed. If this is the case, please contact our customer service.
-
Specifications
Input: 220-240V AC Output: 21 Watt Output voltage: 28 - 40 V DC Frequency: 50/60Hz Powerfactor: >0.50 Dimmable: No IP-rate: IP20 Operation temperature: -25°C ~ 50°C Certificates: CE, EMC, RoHS, TÜV, SAA Warranty: 2 years EAN: 8720365448065 -
Product description
Flicker-free LED Transformer - for Hoftronic 21W LED Panel (180lm/W) - Non-dimmable
This non-dimmable LED transformer is suitable for our LED panels. Thanks to the simple plug & play system, it is super easy to add or remove the LED panel.
Product properties
- Output: The driver delivers an output of 28-40 volts DC
- IP20 degree of protection: Suitable for all dry areas
Not dimmable
This LED driver converts current to the desired operating level for LED lighting.
IP20 protection degree
This driver has IP20 protection, which means it is suitable for all dry areas. Do you wish to install it outside? Then make sure you use a junction box because the transformer is not suitable for damp spaces. If it comes into contact with moisture, it will fail. It is therefore very important to mount it safely in a junction box when installing in damp rooms.
Installation
The LED driver is easy to connect and is delivered ready to install. You can find the installation instructions on our download page. If you want to install the transformer outdoors, it should be placed in an IP65 junction box.
Flicker-free LED Transformer - for Hoftronic 21W LED Panel (180lm/W) - Non-dimmable
This non-dimmable LED transformer is suitable for our LED panels. Thanks to the simple plug & play system, it is super easy to add or remove the LED panel.
Product properties
- Output: The driver delivers an output of 28-40 volts DC
- IP20 degree of protection: Suitable for all dry areas
Not dimmable
This LED driver converts current to the desired operating level for LED lighting.
IP20 protection degree
This driver has IP20 protection, which means it is suitable for all dry areas. Do you wish to install it outside? Then make sure you use a junction box because the transformer is not suitable for damp spaces. If it comes into contact with moisture, it will fail. It is therefore very important to mount it safely in a junction box when installing in damp rooms.
Installation
The LED driver is easy to connect and is delivered ready to install. You can find the installation instructions on our download page. If you want to install the transformer outdoors, it should be placed in an IP65 junction box.
Input: | 220-240V AC |
Output: | 21 Watt |
Output voltage: | 28 - 40 V DC |
Frequency: | 50/60Hz |
Powerfactor: | >0.50 |
Dimmable: | No |
IP-rate: | IP20 |
Operation temperature: | -25°C ~ 50°C |
Certificates: | CE, EMC, RoHS, TÜV, SAA |
Warranty: | 2 years |
EAN: | 8720365448065 |
Flicker-free LED Transformer - for Hoftronic 21W LED Panel (180lm/W) - Non-dimmable
This non-dimmable LED transformer is suitable for our LED panels. Thanks to the simple plug & play system, it is super easy to add or remove the LED panel.
Product properties
- Output: The driver delivers an output of 28-40 volts DC
- IP20 degree of protection: Suitable for all dry areas
Not dimmable
This LED driver converts current to the desired operating level for LED lighting.
IP20 protection degree
This driver has IP20 protection, which means it is suitable for all dry areas. Do you wish to install it outside? Then make sure you use a junction box because the transformer is not suitable for damp spaces. If it comes into contact with moisture, it will fail. It is therefore very important to mount it safely in a junction box when installing in damp rooms.
Installation
The LED driver is easy to connect and is delivered ready to install. You can find the installation instructions on our download page. If you want to install the transformer outdoors, it should be placed in an IP65 junction box.
